Description
The Falcon W501CP6D LAT 622 is an affordable cylindrical lock designed for low to moderate traffic commercial doors in government, retail, industrial, and multi-family buildings. It combines solid construction with budget-friendly pricing, making it ideal when you need dependable security without premium costs.
This lock accepts standard 6-pin cylinders and SFIC interchangeable cores compatible with Schlage, Corbin-Russwin, Yale, and Sargent products. Fits doors 1-3/8" to 1-3/4" thick with standard 2-3/4" backset. As an authorized Falcon dealer, E.D. Locks provides expert support and keying guidance. Contact sales@edlocks.com or call 1-877-207-6067 for assistance selecting the right keyway and configuration for your application.
Specifications
- Brand: Falcon
- Model: W501CP6D LAT 622
- Door Thickness: 1-3/8" to 1-3/4" standard
- Backset: 2-3/4" standard; 2-3/8" also available
- Cylinder: 6-pin removable pinning
- Bolt Projection: 1/2" stainless steel
- Latch Face: 1-1/8" x 2-1/4" (2-3/4" backset)
- Keyways: G keyway standard on conventional cylinders; A keyway on I/C cores
- Schlage C Keyway: Available with master key option
- Compatible Cylinders: Falcon, Schlage, Corbin-Russwin, Yale, Sargent
- Trim: Heavy brass or bronze roses; pressure-cast zinc levers
- UL Listed: 3-hour door assemblies
- Keys Included: Two nickel silver keys standard
