Sargent 80 Series 12-NB8740E RHR Exit Device

The Sargent 80 Series exit device is a heavy-duty panic hardware solution for wood and metal doors in commercial buildings. Built for environments demanding maximum security and durability, this Grade 1 certified device features rim configuration and exceeds ANSI/BHMA cycle and strength requirements with modular construction and minimal moving parts.

This right-hand reverse (RHR) model fits 1-3/4" thick doors with 24-32" door widths using the E Rail (no cutting required for 32" doors). The 80 Series supports optional delayed egress, alarmed exit, and electric latch retraction features. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert configuration guidance and authorized dealer support.

Specifications

• Model: 12-NB8740E RHR 32D
• Configuration: Rim, right-hand reverse
• Compatible door thickness: 1-3/4" (44mm)
• Door width range: 24-32" (61-81cm) with E Rail
• Minimum stile width: 4-1/2" (114mm) with trim; 3-1/2" (44mm) without trim
• Grade certification: ANSI/BHMA Grade 1
• Door material: Wood or metal
• Options available: Delayed egress, alarmed exit, electric latch retraction
