Description
The Sargent 80 Series Rim Exit Device is a Grade 1 panic hardware solution designed for wood and metal doors in commercial and institutional buildings. This single-point latching device delivers durable security with minimal maintenance, ideal for facilities requiring reliable emergency egress that meets ANSI/BHMA standards and UL Fire and Panic listings.
This rim configuration fits doors 24 to 48 inches wide and 1 3/4 inches thick, with rail options (E, F, J, G) matching specific widths for seamless installation. Modular construction with few moving parts ensures long-term reliability. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for compatibility verification, keying assistance, and expert guidance on options like delayed egress or alarmed configurations.
Specifications
- Model: 125556-8844G 4
- Series: Sargent 80
- Configuration: Rim Exit Device
- Door Thickness: 1 3/4 inches (44mm) standard; over 1 3/4 inch requires 31-prefix order
- Door Widths: 24 to 48 inches depending on rail selection (E Rail: 24-32 inch; F Rail: 33-36 inch; J Rail: 37-42 inch; G Rail: 43-48 inch)
- Applications: Single and double doors with mullions
- Latch Type: Single point latching
- Standards: ANSI A156.3 Grade 1, UL Fire and Panic Listed
- Features: Quiet operation, modular construction, maintenance-free
