Description
The LCN 1460 Series is a Grade 1 commercial door closer designed for maximum versatility in institutional and commercial applications. Built with a cast iron body, full complement bearing, and 1-1/4 inch diameter piston, it accommodates interior doors up to 5 feet and exterior doors up to 4 feet. Spring size adjusts from 1 to 6, and the non-handed cylinder works on either right or left swinging doors.
The 1460-62PA US10 mounts on the hinge side or top jamb with regular, top jamb, or parallel arm installation options. Multiple cover styles and finishes including standard powder coat and optional plated finishes are available. As an authorized LCN dealer, E.D. Locks provides expert guidance on selection, finish options, and installation. Contact us at sales@edlocks.com or 1-877-207-6067 for assistance.
Specifications
- Brand: LCN
- Series: 1460
- Grade: 1
- Body Material: Cast iron
- Piston Diameter: 1-1/4 inch
- Pinion Journal Diameter: 3/4 inch
- Spring Adjustment: Size 1 to 6
- Interior Door Capacity: Up to 5 feet
- Exterior Door Capacity: Up to 4 feet
- Installation Options: Regular arm, top jamb, parallel arm
- Application: Hinge side or top jamb mount
- Handed: Non-handed, universal reversible
- Cycle Tested: 2,000,000 cycles
- Finish Options: Standard powder coat, optional plated, optional SRI primer
- Features: ADA compliant, Cush-N-Stop function, concealed adjustment valves
