Description
The LCN 1460 Series is a Grade 1 commercial door closer designed for maximum versatility in both commercial and institutional applications. With a cast iron body, full complement bearing, and adjustable spring sizes 1-6, it solves the need for reliable, durable door control on interior doors up to 5'0" and exterior doors up to 4'0".
This closer mounts on the hinge side or top jamb and works with right or left swinging doors, meeting ADA requirements. Compatible with multiple cover options and finish choices, including optional SRI primer for corrosive environments. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on parts, installation, and custom configurations.
Specifications
- Brand: LCN
- Series: 1460
- Grade: 1
- Piston Diameter: 1-1/4 In.
- Pinion Journal Diameter: 3/4 In.
- Spring Adjustment: Size 1 to 6
- Interior Door Maximum Height: 5'0"
- Exterior Door Maximum Height: 4'0"
- Mount Locations: Hinge side, top jamb, parallel arm
- Cycle Rating: 2,000,000 cycles
- Body Material: Cast iron
- ADA Compliant: Yes
- Finish Options: Standard powder coat, optional plated finish, optional SRI primer
