Description
The LCN 1461-LONG is a Grade 1 universal surface-mounted door closer engineered for commercial and institutional applications. Its cast iron body, full-complement bearing, and adjustable spring strength (sizes 1-6) accommodate doors from 5'0" interior to 4'0" exterior. This non-handed closer works on right or left swinging doors and meets ADA requirements, solving the need for reliable, durable door control in high-traffic environments.
Compatible with hinge-side, top-jamb, and parallel-arm mounting options, the 1461-LONG features concealed adjustment valves for backcheck, closing, and latching speeds. As an authorized LCN dealer, E.D. Locks provides expert installation guidance and support at sales@edlocks.com or 1-877-207-6067 to ensure proper setup and long-term performance on your specific door application.
Specifications
- Grade 1 closer with cast iron body
- Full-complement bearing with 1.25 inch diameter piston
- 0.75 inch diameter heat-treated pinion journal
- Adjustable spring size: 1 to 6
- Interior door capacity: up to 5'0"
- Exterior door capacity: up to 4'0"
- Tested to 2,000,000 cycles
- Finish: Brass (standard or optional powder coat, plated, or SRI primer available)
- Installation options: Regular arm, top jamb, or parallel arm
- Universal, fully reversible, non-handed design
- Cush-N-Stop function included
