Description
The SDC 180AIVD is a heavy-duty surface mount bolt lock designed for fail-safe access control on commercial doors and frames. Ideal for facilities managers and security integrators, it solves the need for reliable, electrically-controlled locking in high-traffic environments where manual deadbolts fall short.
This unit operates on 12/24VDC power with auto-relock capability and includes an external recessed magnetic sensor for status monitoring. Compatible with standard door frames and wired access control systems. For expert sizing, voltage selection, and installation guidance, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Operating Voltage: 12/24VDC
- Current Draw: 900mA (12V) / 450mA (24V)
- Dimensions: 6" x 2" x 2"
- Finish: Satin Aluminum Clear Anodized
- Magnetic Sensor: External Recessed, 3/4", SPDT, 30VDC, 50mA
- Function: Fail Safe with Auto Relock
