Description
The Sargent 80 Series exit device is a heavy-duty panic bar for wood and metal doors requiring Grade 1 security and reliability. Ideal for commercial buildings, hospitals, schools and facilities demanding maintenance-free operation, this rim-mounted device exceeds ANSI/BHMA standards and suits doors 1-3/4" thick with 4-1/2" minimum stile width. Its modular design minimizes moving parts while supporting optional features like delayed egress, alarmed exit and electric latch retraction.
This left-hand reverse (LHR) model fits E, F, J and G rail configurations across door widths from 24" to 48". Verify your door thickness and stile width before ordering; thicker doors require a 31-option specification. As an authorized Sargent dealer, E.D. Locks provides expert guidance on sizing, keying and compatibility. Contact sales@edlocks.com or call 1-877-207-6067 for personalized support and free shipping on orders over $450.
Specifications
- Brand: Sargent
- Model: 1943-8343G LHR BSP
- Configuration: Rim-mounted, left-hand reverse
- Door Types: Wood or metal
- Door Thickness: 1-3/4" (44mm); over 1-3/4" specify thickness and order as 31-option
- Minimum Stile Width: 4-1/2" (114mm)
- E Rail: 24" to 32" (61cm to 81cm)
- F Rail: 33" to 36" (84cm to 91cm)
- J Rail: 37" to 42" (94cm to 107cm)
- G Rail: 43" to 48" (110cm to 122cm)
- Standards: Exceeds ANSI/BHMA Grade 1
- Optional Features: Delayed egress, alarmed exit, electric latch retraction
