Description
The Sargent 80 Series exit device is a heavy-duty panic bar designed for metal doors requiring Grade 1 security and reliability. Ideal for commercial facilities, schools, and high-traffic environments, this rim-mounted device exceeds ANSI/BHMA standards and features modular construction with minimal maintenance needs, delivering decades of dependable operation.
This right-hand reverse (RHR) model fits 1 3/4" minimum thickness metal doors with 4 1/2" minimum stile width and includes a 650 top strike and 606 bottom strike for panic and fire-rated applications. Rail size E accommodates 24" to 32" door widths. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for custom configurations, electric options (alarm, photoluminescent, delayed egress), or installation guidance.
Specifications
- Brand: Sargent
- Model: 1943-MD8615E
- Configuration: Rim, RHR (Right Hand Reverse)
- Finish: 32D (Satin Stainless Steel)
- Door Thickness: 1 3/4" minimum (44mm); up to 2 1/4" with specification
- Minimum Stile Width: 4 1/2" (114mm)
- Rail Size: E (24" to 32" door widths, factory cut)
- Strikes: 650 Top, 606 Bottom (panic and fire-rated)
- Device Centerline Height: 41" standard (1041mm); 38" for schools (965mm)
- Center Case: 8 3/8" x 2 5/8" (213mm x 67mm)
- Pushbar Projection: 3" neutral (76mm), 2 1/8" depressed (54mm)
- Top Bolt: Stainless steel
- Dogging: Hex key standard; specify for cylinder dogging
- ANSI/BHMA: Exceeds Grade 1
- Optional Features: Alarm, beacon, photoluminescent coating, illuminated touchpad, latch monitoring, remote retraction, delayed egress, electric dogging
