Description
The Sargent 80 Series exit device is a heavy-duty panic bar solution for metal doors in commercial and institutional buildings. Built to ANSI/BHMA Grade 1 standards, it features rim configuration with left-hand reverse (LHR) orientation, modular construction, and minimal moving parts for reliable, maintenance-free operation across the life of your building.
This unit fits 1 3/4" minimum thickness metal doors with 4 1/2" minimum stile width and includes top and bottom strikes (650/606) rated for panic and fire applications. It supports optional features including delayed egress, alarm, photoluminescent coating, illuminated touchpad, and electric latch retraction. As an authorized Sargent dealer, E.D. Locks provides expert sizing, configuration, and installation guidance. Contact sales@edlocks.com or call 1-877-207-6067 for door-specific specifications and ordering support.
Specifications
- Series: 80 Series
- Configuration: Rim, Left-Hand Reverse (LHR)
- Finish: 32D (Stainless Steel)
- Door Thickness: 1 3/4" minimum (44mm); up to 2 1/4" with special order
- Minimum Stile Width: 4 1/2" (114mm)
- Rails: E, F, J, or G (factory cut to door width)
- Top Strike: 650
- Bottom Strike: 606
- Device Centerline Height: 41" (1041mm) standard; 38" (965mm) for ADA/elementary
- Center Case: 8 3/8" x 2 5/8" (213mm x 67mm)
- Pushbar Projection: 3" neutral (76mm), 2 1/8" depressed (54mm)
- Dogging: Hex key standard; cylinder dogging available (#41 cylinder)
- Standards: ANSI/BHMA Grade 1, panic and fire rated
