Description
The Sargent 80 Series exit device is a heavy-duty crash bar solution for wood and metal doors in commercial buildings. Designed for facilities requiring ANSI/BHMA Grade 1 certified security, it combines durable rim construction with modular design to minimize maintenance while maximizing egress safety and operational reliability.
This left-hand reverse (LHR 3) model fits doors 1-3/4 inches thick with 4-1/2-inch minimum stiles and supports G rail configuration (43-48 inches wide). Optional features include delayed egress, alarmed exit, and electric latch retraction. Contact E.D. Locks & Security at sales@edlocks.com or 1-877-207-6067 for expert help selecting the right configuration and installation support.
Specifications
- Brand: Sargent
- Model: 194356-8343G LHR 3
- Type: Rim exit device
- Hand: Left-hand reverse
- Door thickness: 1-3/4 inches (44mm)
- Minimum stile width: 4-1/2 inches
- Rail type: G Rail
- Door width range: 43-48 inches (110-122cm)
- Standard door width: 48 inches (no cutting required)
- Certifications: ANSI/BHMA Grade 1
- Door material: Wood or metal
- Optional features: Delayed egress, alarmed exit, electric latch retraction
