Description
The Sargent 80 Series exit device delivers Grade 1 security for wood and metal doors in high-traffic facilities. This rim-mounted panic bar combines modular construction with minimal moving parts, ensuring maintenance-free operation and durability that lasts the life of your building. Ideal for schools, offices, hospitals, and commercial properties requiring reliable emergency egress.
Compatible with 1 3/4 inch standard doors and stiles 4 1/2 inches minimum; the J rail configuration fits doors 37 to 42 inches wide with no cutting required at 42 inches. For custom door dimensions, thickness specifications, or to explore delayed egress and electric latch retraction options, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- Brand: Sargent
- Model: 80 Series 194356-8343J RHR 3
- Type: Rim Exit Device, Right Hand Reverse
- Door Compatibility: Wood or metal, 1 3/4 inch thick
- Minimum Stile Width: 4 1/2 inches
- Rail Type: J Rail
- Door Width Range: 37 to 42 inches (94cm to 107cm)
- No Cutting Required: 42 inch doors
- Certification: Exceeds ANSI/BHMA Grade 1
- Construction: Modular with few moving parts
