Description
The Von Duprin 230TP 622 is a Grade 1 rim exit device designed for single and double doors on commercial buildings. This UL-listed panic hardware meets ANSI A156.3 2008 standards and fits hollow metal doors with 161-inch cutouts and stiles as narrow as 3 13/16 inches, solving emergency egress requirements for high-traffic facilities.
The 230TP 622 ships ready for multiple functions (EO, DT, NL, TP, K, L) in 3-foot or 4-foot lengths and accepts optional electric monitoring, alarm, and mechanical upgrades. As an authorized Von Duprin dealer, E.D. Locks provides expert configuration support and can help you select the right strike and dogging options. Contact sales@edlocks.com or call 1-877-207-6067 for assistance.
Specifications
- Brand: Von Duprin
- Model: 230TP 622
- Grade: ANSI A156.3 2008 Grade 1
- Type: Rim Exit Device (Panic Hardware)
- Suitable for: Single and double doors with or without mullion
- UL Listed: Yes
- Non-handed: Yes
- Device lengths: 3 feet (914 mm), 4 feet (1219 mm)
- Minimum door stile width: 3 13/16 inches (97 mm)
- Compatible cutouts: 161-inch hollow metal doors
- Centerline from finished floor: 39 13/16 inches (1011 mm) or 39 11/16 inches (1008 mm) with mullion
- Center case dimensions: 4 1/4 inches (108 mm) x 1 3/8 inches (41 mm) x 2 3/8 inches (60 mm)
- Mechanism case dimensions: 2 inches (51 mm) x 3 3/4 inches (95 mm)
- Push bar projection (neutral): 3 3/4 inches (95 mm)
- Push bar projection (depressed): 3 inches (76 mm)
- Latch bolt: Deadlocking, 3/4 inch (19 mm) throw
- Standard fasteners: 1 3/4 inch (44 mm) and 2 1/4 inch (57 mm) sex bolts for wood and metal doors
- Dogging: Hex key standard; less dogging (LD) option available
- Factory functions: EO, DT, NL, TP, K, L
- Electric options: LX latchbolt monitor switch, RX pushpad monitor switch, RX2 double pushpad monitor switch, ALK alarm exit kit, CON Allegion Connect
- Mechanical options: GBK glass bead kit, AX accessible device
- Strike: 299 Dull Black Von Duprin
