Description
The Sargent 6500 Series is a standard duty key-in-lever lock built to ANSI A156.2 Series 4000 Grade 2 standards. Ideal for commercial and institutional doors, it provides reliable keyed access control for interior and exterior applications on doors 1-3/8" to 1-3/4" thick. The universal hand design fits any door orientation without reordering.
This lock is pre-configured with a 2-3/4" backset, 6-pin brass cylinder with LA keyway, and stainless steel front and strike for durability. Ships with two nickel silver keys and installs on standard ANSI A115.2 (161) Modified bore prep. E.D. Locks is an authorized Sargent dealer; contact our team at sales@edlocks.com or 1-877-207-6067 for keying options, finish specifications, and expert installation guidance.
Specifications
- Brand: Sargent
- Series: 6500 Line
- Function: Key-In Lever
- Grade: ANSI A156.2 Series 4000 Grade 2
- Door Thickness: 1-3/8" to 1-3/4" (35-44mm)
- Backset: 2-3/4" (70mm) standard
- Front Plate: Wrought brass and stainless steel, 2-1/4" x 1-1/8"
- Latch: Brass, 1/2" (13mm) throw
- Cylinder: Brass, 6 pin, LA keyway
- Keys: Two nickel silver
- Strike: 600 Curved Lip, stainless steel standard
- Finish: 26D
- Hand: Universal
- Door Prep: ANSI A115.2 (161) Modified
- Minimum Stile: 4-1/2" (114mm)
