Description
The DormaKaba 3010-19-41 is an electronic keypad drive assembly designed for secure access control on aluminum-framed glass doors. Built for high-traffic commercial facilities, this vandal-resistant unit combines a force-resistant cast metal housing with solid metal pushbuttons to deliver reliable performance in demanding environments where traditional keys are impractical.
Compatible with Adams Rite 4510, 4710, and 4910 mortise latches, this drive assembly accepts Maximum Security mortise cylinders for master-key override capability and master-keyed system flexibility. Installation requires a minimum 1⅞ inch stile width and fits doors up to 1¾ inches thick. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on compatibility, keying options, and installation support.
Specifications
- Drive Assembly Size: 31/32 inch, Right Hand/Right Hand Reverse
- Housing: All metal cast front, force-resistant and clutch-protected fixed thumbturn
- Keypad: Vandal resistant with solid metal pushbuttons
- Key Override: Accepts Maximum Security mortise cylinders
- Compatible Latches: Adams Rite 4510, 4710, 4910 (purchased separately)
- Minimum Stile Width: 1⅞ inch (48 mm)
- Maximum Door Thickness: 1¾ inch (44 mm)
- Strike: Sold separately (Adams Rite or Kaba Ilco Corp.)
- Weather Resistant: Yes
- Warranty: 1 year
- Included: Installation instructions, full-scale template, combination change key, screwdriver
