Description
The DormaKaba 3020-19-41 is an electronic mortise drive assembly with a vandal-resistant numeric keypad, designed for secure access control on aluminum stile doors. Its force-resistant, clutch-protected thumbturn and all-metal cast housing make it ideal for high-traffic commercial facilities requiring keyless entry without sacrificing durability or security.
Compatible with Adams Rite 4510/4710/4910 mortise latches (sold separately) and Maximum Security mortise cylinders for master-key override capability. Installation requires a minimum 1⅞ inch stile width and 1¾ inch maximum door thickness. As an authorized DormaKaba dealer, E.D. Locks offers expert installation guidance and ongoing support. Contact our team at sales@edlocks.com or 1-877-207-6067 for compatibility questions or technical assistance.
Specifications
- Drive Assembly Model: 3020-19-41
- Stile Width Required: 1⅞ inch (48 mm) minimum
- Door Thickness: 1¾ inch (44 mm) maximum
- Compatible Latch: Adams Rite 4510/4710/4910 (sold separately)
- Compatible Cylinder: Maximum Security (MS) mortise cylinders
- Keypad: Vandal-resistant solid metal pushbuttons
- Thumbturn: Force-resistant, clutch-protected fixed
- Housing: All metal cast front
- Weather Resistance: Yes
- Warranty: 1 year
- Included: Installation instructions, full-scale template, combination change key, screwdriver
