Description
The Von Duprin 33AEO 4 26D is a UL-listed panic exit device designed for single and double doors with mullion. Built to ANSI A156.3 2014 Grade 1 standards, it provides reliable emergency egress for commercial buildings, schools, hospitals, and facilities requiring code-compliant life safety hardware. The grooved case mechanism delivers dependable performance in high-traffic environments.
This rim-mounted device suits door sizes from 2'4" to 4' and accepts multiple electric and dogging options including latch monitoring, signal switches, and electric latch retraction. As an authorized Von Duprin dealer, E.D. Locks provides expert configuration assistance and access to genuine parts. Contact our team at sales@edlocks.com or 1-877-207-6067 for specification verification and installation guidance.
Specifications
- Model: 33AEO 4 26D
- Grade: ANSI A156.3 2014 Grade 1
- Compatible door sizes: 2'4" to 4' height
- Latch bolt: Deadlocking, 3/4" throw
- Case dimensions: 8 3/16" x 2 13/32" x 1 9/16"
- Centerline height: 39 13/16" from finished floor
- Pushbar projection: 3 13/16" neutral, 3 1/16" depressed
- Strike: 1439 Dull Black
- Dogging: Hex key standard; CD Cylinder or LD options available
- Electric options: LX, RX, RX2, SS, EL, ALK compatible
- Non-handed (except with SS signal switch option)
