Description
The Von Duprin 35ANL 3 is a UL-listed rim exit device designed for single and double doors with mullions. Built to ANSI A156.3-2014 Grade 1 standards, this panic hardware provides reliable emergency egress for commercial facilities. The smooth mechanism case suits modern aesthetics while meeting all life safety codes.
Compatible with door sizes 4'2" to 4' (864-1219mm), the 35ANL 3 installs on both wood and metal doors using included fasteners. Non-handed design simplifies inventory and installation. As an authorized Von Duprin dealer, E.D. Locks offers expert guidance on finishes, functions, and compliance. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for specification details and quotes.
Specifications
- Brand: Von Duprin
- Model: 35ANL 3 643E RHR
- Standard: ANSI A156.3-2014 Grade 1, UL Listed
- Device Length: 2'4" to 3' (711-914mm)
- Door Size: 4'2" to 4' (864-1219mm)
- Center case: 8 3/16" x 1 9/16" x 2 13/32" (208 x 40 x 62mm)
- Mechanism case: 2 1/4" x 2 1/4" (57 x 57mm)
- Pushbar projection (neutral): 3 13/16" (97mm)
- Pushbar projection (depressed): 3 1/16" (78mm)
- Latch bolt: Deadlocking, 3/4" (19mm) throw
- Non-handed (except with signal switch option)
- Compatible with wood and metal doors
