Description
The LCN 4030 is a cast iron universal door closer designed for moderate traffic environments. It solves the need for reliable, code-compliant automatic door closing on standard swinging doors up to 48 inches. Facility managers and building owners choose the 4030 Series for its versatility, durability, and ADA compliance in offices, schools, and commercial buildings.
This right-hand aluminum arm mounts on the hinge side, top jamb, or parallel arm configuration. The 4031 cylinder accommodates exterior doors to 36 inches and interior doors to 48 inches. As an authorized LCN dealer, E.D. Locks offers expert sizing assistance, finish options including powder coat and plated finishes, and SRI primer for corrosive environments. Contact sales@edlocks.com or call 1-877-207-6067 for installation guidance and custom specifications.
Specifications
- Brand: LCN
- Model: 4030-3049EDA RH
- Arm Type: Forged regular arm, aluminum
- Mounting Options: Hinge side, top jamb, parallel arm
- Cylinder: Non-sized (1-4) 4031
- Max Door Width Exterior: 36 inches (914 mm)
- Max Door Width Interior: 48 inches (1219 mm)
- Hand: Right hand
- Material: Cast iron closer body
- Certifications: UL, cUL listed; ANSI A156.4 Grade One
- ADA Compliant: Yes
- Finish Options: Standard powder coat, optional plated finish, optional SRI primer
