Description
The LCN 4040XP is a heavy-duty door closer arm engineered for high-traffic institutional and commercial applications. It features 44% increased bearing load capacity, the strongest pinion at 3/4" journal diameter, and LCN's V-shield seal technology for extended durability. Ideal for facilities demanding maximum performance and reliability in demanding environments.
This non-handed closer mounts on hinge side, top jamb, or parallel arm configuration for right or left swinging doors up to 5'0" interior and 4'0" exterior. It's UL and cUL listed, ANSI A156.4 grade one certified, and compatible with all 4040 accessories. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on mounting options and finish selections.
Specifications
- Brand: LCN
- Model: 4040XP-3077EDA/G
- Finish: Black Powder Coat
- Pinion Journal Diameter: 3/4 inch
- Bearing Width: 5/8 inch
- Interior Door Height: Up to 5'0 inch
- Exterior Door Height: Up to 4'0 inch
- Non-Handed Design
- Mounting Options: Hinge side, top jamb, or parallel arm
- Certifications: UL and cUL Listed, ANSI A156.4 Grade One
- Features: V-shield seal, fast power adjust, all-weather fluid
