Description
The LCN 4040XP is a heavy-duty institutional door closer engineered for high-traffic commercial and institutional settings. With 44% increased bearing load capacity, a 3/4" journal diameter pinion, and a reinforced V-shield seal offering 20% longer life, this closer delivers superior durability and reliability in demanding applications. Ideal for facilities managers and building owners seeking maximum performance and minimal maintenance.
This non-handed closer installs on hinge side, top jamb, or parallel arm configuration for both right and left swinging doors, accommodating interior doors to 5'0" and exterior doors to 4'0". It is UL and cUL listed, meets ANSI A156.4 Grade One, and supports ADA compliance. Our authorized dealer team at E.D. Locks can help you select the right mounting hardware and finish options. Contact sales@edlocks.com or call 1-877-207-6067 for expert guidance.
Specifications
- Brand: LCN
- Model: 4040XP-72MC LH
- Finish: US10
- Bearing Load Capacity: 44% increased
- Pinion Journal Diameter: 3/4 inch
- Bearing Width: 5/8 inch
- V-shield Seal Life: 20% longer
- Interior Door Range: Up to 5 feet 0 inches
- Exterior Door Range: Up to 4 feet 0 inches
- Mounting Options: Hinge side, top jamb, parallel arm
- Certifications: UL and cUL Listed, ANSI A156.4 Grade One
- ADA Compliance: Supported
- Finish Options: Standard or custom powder coat, optional plated finish, optional SRI primer for corrosive environments
