Description
The LCN 4040XP-72MC is a heavy-duty door closer engineered for high-traffic institutional and commercial environments. With 44% increased bearing load capacity, a 3/4" journal pinion, and reinforced steel construction, it delivers maximum durability and reliable performance in demanding applications where standard closers fall short.
This closer accommodates interior doors to 5'0" and exterior doors to 4'0", and mounts on hinge side, top jamb, or parallel arm on either right or left swinging doors. It meets ADA requirements and is UL and cUL listed to ANSI A156.4 grade one. As an authorized LCN dealer, E.D. Locks provides expert guidance on sizing, installation, and finish options including powder coat and optional corrosion-resistant SRI primer. Contact sales@edlocks.com or 1-877-207-6067 for specification assistance.
Specifications
- Brand: LCN
- Model: 4040XP-72MC LH
- Finish: US26 (Satin Chrome)
- Bearing Load Capacity: 44% increased
- Pinion Journal Diameter: 3/4"
- Bearing Width: 5/8"
- Interior Door Range: to 5'0"
- Exterior Door Range: to 4'0"
- Seals: V-shield with 20% extended life
- Construction: Cast iron, forged steel arm, double heat-treated steel pinion
- Fluid: All-weather
- Mounting: Hinge side, top jamb, or parallel arm compatible
- Certifications: UL and cUL listed, ANSI A156.4 grade one
- ADA Compliant: Yes
- Adjustability: Non-sized cylinder with fast power adjust
