Description
The LCN 4040XP-77 AL is a heavy-duty institutional door closer engineered for high-traffic environments demanding maximum durability. Features include 44% increased bearing load capacity, the strongest pinion at 3/4" journal diameter, and an enhanced V-shield seal with 20% longer life. Non-handed design works on either right or left swinging doors, with flexible mounting options (hinge side, top jamb, or parallel arm) for interior doors to 5'0" and exterior doors to 4'0".
This UL and cUL listed closer meets ANSI A156.4 grade one standards and accommodates ADA requirements. Installation is fast and accurate with LCN Fast Power Adjust technology. As an authorized E.D. Locks dealer, we provide expert support at sales@edlocks.com or 1-877-207-6067 to ensure proper specification and installation for your application. All Weather fluid, optional powder coat and plated finishes available.
Specifications
- Brand: LCN
- Model: 4040XP-77 AL
- Type: Heavy-Duty Institutional Door Closer
- Bearing Load Capacity: 44% increase over standard
- Pinion Journal Diameter: 3/4"
- Bearing Width: 5/8"
- Seal: V-shield with 20% longer life
- Interior Door Range: Up to 5'0"
- Exterior Door Range: Up to 4'0"
- Mounting Options: Hinge side, top jamb, or parallel arm
- Handed: Non-handed (right or left swing)
- Fluid: All Weather
- Certifications: UL and cUL listed, ANSI A156.4 Grade One
- ADA Compliant: Yes
- Finish Options: Standard, optional powder coat, optional plated finish, optional SRI primer
- Accessories: Compatible with all 4040 accessories
