Description
The LCN 4040XP-79LR is a heavy-duty door closer engineered for high-traffic institutional environments. Its reinforced pinion and expanded bearing capacity deliver 44% increased load capacity, making it ideal for facilities managing demanding door cycles. The V-shield seal extends service life by 20%, reducing maintenance costs and downtime.
This non-handed closer mounts on hinge side, top jamb, or parallel arm positions for doors up to 5 feet interior or 4 feet exterior. UL and cUL listed for ADA compliance, it features adjustable power settings and fast installation. Contact our team at sales@edlocks.com or 1-877-207-6067 for expert sizing, finish selection, and application support.
Specifications
- Brand: LCN
- Model: 4040XP-79LR 651
- Pinion Journal Diameter: 3/4 inch
- Bearing Width: 5/8 inch
- Interior Door Capacity: Up to 5 feet 0 inches
- Exterior Door Capacity: Up to 4 feet 0 inches
- Seal Type: V-shield with extended life
- Material: Cast iron, forged steel arm, double heat treated steel pinion
- Fluid Type: All weather
- Handed: Non-handed
- Certifications: UL and cUL listed, ANSI A156.4 grade one
- Mount Options: Hinge side, top jamb, or parallel arm
- Finish Options: Standard or custom powder coat; optional plated finish; optional SRI primer for corrosive environments
- Features: Fast power adjust, fast and accurate installation
