Description
The Sargent 80 Series exit device is a heavy-duty panic bar built for commercial facilities requiring lasting, Grade 1 security. Ideal for wood or metal doors 1-3/4" to 2-1/4" thick, this rim-mounted RHR device suits standard entry widths 24" to 42" and exceeds ANSI/BHMA Grade 1 cycle and strength requirements with few moving parts.
This model ships ready for 32" doors; wider installations may require rail sizing. Modular design ensures minimal maintenance over the building's life. For door thickness over 2-1/4", order with a 31-prefix. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for compatibility verification, keying options, and expert installation guidance.
Specifications
- Brand: Sargent
- Model: 4356-NB8743J RHR 32D
- Type: Rim Exit Device
- Configuration: Right Hand Reverse (RHR)
- Standard Door Thickness: 1-3/4" (44mm)
- Extended Thickness: Over 1-3/4" to 2-1/4" (specify and order with 31-prefix)
- Minimum Stile: 4-1/2" (114mm) with trim; 3-1/2" (44mm) without trim
- Door Widths - E Rail: 24" to 32" (no cutting at 32")
- Door Widths - F Rail: 33" to 36" (no cutting at 36")
- Door Widths - J Rail: 37" to 42" (no cutting at 42")
- Door Widths - G Rail: 43" to 48" (no cutting at 48")
- Material: Metal and wood door compatible
- Grade: ANSI/BHMA Grade 1
- Features: Modular construction, maintenance-free, options for delayed egress and alarmed exit
