Description
The Sargent 4356 80 Series exit device delivers Grade 1 panic hardware for metal doors in commercial and institutional settings. Engineered for durability and low maintenance, this right-hand reverse rim device meets ANSI/BHMA requirements and suits buildings demanding reliable egress solutions with optional delayed egress, alarm, and electric latch retraction features.
Fits 37 to 42 inch door widths with J-rail configuration and 1-3/4 inch minimum door thickness. Includes stainless steel top bolt, 650 top strike, and 606 bottom strike. As an authorized Sargent dealer, E.D. Locks provides expert configuration guidance and fast shipping. Contact our sales team at sales@edlocks.com or 1-877-207-6067 to verify your door specifications and select compatible accessories.
Specifications
- Brand: Sargent
- Model: 4356-WD8610J ETW RHR 32D
- Type: Rim Exit Device, 80 Series
- Hand: Right-Hand Reverse
- Rail: J (37-42 inch doors)
- Door Thickness: 1-3/4 inch minimum
- Door Height: Specify up to 120 inch maximum
- Stile Width: 4-1/2 inch minimum
- Center Case Dimensions: 8-3/8 inch x 2-5/8 inch
- Pushbar Projection: 3 inch neutral, 2-1/8 inch depressed
- Device Centerline: 41 inch from finished floor
- Top Bolt: Stainless steel
- Strike: 650 top, 606 bottom
- Dogging: Hex key standard
- Fasteners: Machine screws supplied
- Rating: ANSI/BHMA Grade 1
