Description
The Sargent 80 Series exit device is a heavy-duty panic bar solution for metal doors in commercial and institutional buildings. Designed for facilities requiring durable, long-lasting security, this rim-mounted device exceeds ANSI/BHMA Grade 1 standards for cycle strength and reliability. Its modular construction with minimal moving parts ensures minimal maintenance while delivering consistent performance.
This right-hand reverse (RHR) model suits metal doors 1 3/4 inches minimum thickness and accommodates door widths from 24 to 48 inches with field-selectable rail sizes. Electric options including delayed egress, alarming, and latch retraction are available for specialized applications. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on configuration, compatibility, and custom options.
Specifications
- Model: 5556-AD8606F RHR 10BE
- Brand: Sargent
- Series: 80 Series
- Configuration: Rim Mount, Right-Hand Reverse
- Door Type: Metal doors, 1 3/4 inch (44mm) minimum thickness
- Door Width Range: 24 to 48 inches (rail-dependent)
- Maximum Door Opening Height: 96 inches
- Device Centerline Height: 41 inches (1041mm) standard
- Center Case Dimensions: 8 3/8 inches x 2 5/8 inches (213mm x 67mm)
- Pushbar Projection (Neutral): 3 inches (76mm)
- Pushbar Projection (Depressed): 2 1/8 inches (54mm)
- Strike: 650 Top and 606 Bottom
- Top Bolt: Stainless steel
- Standard Dogging: Hex key (non-fire rated)
- Rating: Exceeds ANSI/BHMA Grade 1
- Electric Options Available: Alarm, Beacon, photoluminescent coating, illuminated touchpad, latch monitoring, delayed egress, remote latch retraction, electric dogging
