Description
The Sargent 80 Series rim exit device is a commercial-grade panic bar designed for wood and metal doors requiring ANSI/BHMA Grade 1 strength and durability. Ideal for facilities prioritizing security and long-term reliability, this device features modular construction with minimal moving parts, delivering maintenance-free operation and consistent performance across the building's life.
This right-hand reverse (RHR) model suits 1 3/4 inch thick doors with adjustable rail options for door widths from 24 to 48 inches. Sargent offers optional configurations including delayed egress, alarmed exit, and electric latch retraction for specialized applications. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert specification assistance and competitive pricing.
Specifications
- Series: 80 Series
- Model: 56-8506E ETP RHR 10B
- Configuration: Rim Exit Device, Right-Hand Reverse
- Door Thickness: 1 3/4 inch (44mm) standard; over 1 3/4 inch specify thickness with 31- prefix
- Minimum Stile Width: 1 3/4 inch (44mm)
- Door Width Ranges: E Rail 24-32 inches, F Rail 33-36 inches, J Rail 37-42 inches, G Rail 43-48 inches
- Standard Size: No cutting required at nominal widths (32, 36, 42, 48 inches)
- Performance: Exceeds ANSI/BHMA Grade 1 cycle and strength requirements
- Door Types: Wood or metal
