Description
The Adams Rite 8611TLR-36 is a concealed vertical rod exit device designed for narrow stile doors requiring reliable emergency egress. Built for facilities managers and safety directors, this electric latch retraction model solves the need for code-compliant panic hardware that integrates seamlessly into modern building designs without visible vertical rods.
This device fits standard 1 3/4 inch to 2 1/4 inch door thickness and adjusts from 30 to 44 inches in bar height, accommodating doors up to 8 feet tall. It is non-handed with field-reversible lever entry trim for flexible installation. As an authorized Adams Rite dealer, E.D. Locks provides expert guidance on cylinder compatibility, dogging options, and tall door kits. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized specification support.
Specifications
- Brand: Adams Rite
- Model: 8611TLR-36
- Series: 8600 Narrow Stile Concealed Vertical Rod
- Configuration: Top Rod Only
- Function: Electric Latch Retraction
- Door Opening Width: 36 inches
- Finish: Satin Aluminum Clear Anodized
- Pushbar Material: Extruded aluminum
- Handing: Non-handed
- Bar Height Adjustment: 30 to 44 inches
- Maximum Door Height: 8 feet (standard)
- Door Thickness: 1 3/4 inch standard, up to 2 1/4 inch
- Minimum Stile Width: 3 3/4 inches
- Projection: 2 15/16 inches fully projected, 1 15/16 inches dogged
- Dogging: Standard hex key dogging
- Fasteners: Self-tapping screws
- Cylinder: Accepts standard rim cylinder (sold separately)
- Warranty: Five year limited
