Description
The Adams Rite 8622MLR-30 is a Grade 1 narrow stile concealed vertical rod exit device designed for aluminum storefront and curtainwall applications. Built for high-traffic commercial doors, it features motor latch retraction and electric dogging for convenient egress control and operator access without manual unlocking.
This non-handed device fits standard 1 3/4" to 2 1/4" door thickness and accommodates doors up to 8 ft tall with adjustable bar height from 30" to 44". The extruded aluminum pushbar is finished in dark bronze anodized aluminum. As an authorized Adams Rite dealer, E.D. Locks provides expert guidance on compatibility, handing options, and cylinder selection. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for installation support and to verify your specific door configuration.
Specifications
- Brand: Adams Rite
- Model: 8622MLR-30
- Type: Concealed Vertical Rod Exit Device
- Grade: 1
- Pushbar Length: 30"
- Material: Extruded aluminum
- Finish: Dark bronze anodized aluminum
- Latch Retraction: Motor
- Dogging: Electric
- Handing: Non-handed, field reversible
- Door Thickness: 1 3/4" standard, up to 2 1/4"
- Bar Height Adjustment: 30" to 44"
- Door Height: Up to 8 ft standard (tall door kits available separately)
- Minimum Stile Width: 3 3/4"
- Projection: 2 15/16" fully projected, 1 15/16" when dogged
- Warranty: Five year limited
