Description
The Adams Rite 8622MLR-48 is a Grade 1 narrow stile concealed vertical rod exit device designed for aluminum storefront and curtainwall applications. Built for high-traffic commercial doors, it combines motor latch retraction with electric dogging to meet ADA compliance and life safety codes while reducing operational wear.
This 48-inch pushbar device fits standard door heights up to 8 feet and suits door thicknesses from 1-3/4 to 2-1/4 inches. The non-handed design with field-reversible entry trim simplifies inventory and installation. As an authorized Adams Rite dealer, E.D. Locks offers expert consultation on compatibility, keying options, and tall-door kits. Contact sales@edlocks.com or call 1-877-207-6067 for application guidance and a five-year limited warranty.
Specifications
- Brand: Adams Rite
- Model: 8622MLR-48
- Grade: 1
- Pushbar Length: 48 inches
- Bar Height Range: 30 to 44 inches (adjustable)
- Door Height Capacity: Up to 8 feet (standard)
- Door Thickness: 1-3/4 to 2-1/4 inches
- Stile Width: Minimum 3-3/4 inches
- Finish: Dark Bronze Anodized Aluminum
- Material: Extruded aluminum pushbar
- Handing: Non-handed, field reversible
- Projection: 2-15/16 inches (extended), 1-15/16 inches (dogged)
- Dogging: Electric dogging
- Latch Retraction: Motor latch retraction
- Application: Aluminum narrow stile
- Warranty: Five year limited
