Description
The Sargent 8706J is a heavy-duty rim exit device built for commercial and industrial facilities that demand Grade 1 security and reliability. This right-hand reverse (RHR) model fits 32-inch doors and suits environments where durable, maintenance-free egress hardware is essential for safety and compliance.
Installation fits wood or metal doors 1 3/4" thick with a minimum 4 1/2" stile (with trim). The 80 Series exceeds ANSI/BHMA Grade 1 cycle and strength requirements, and optional features include delayed egress, alarm, and electric latch retraction. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert sizing, configuration advice, and fast shipping on all Sargent products.
Specifications
- Model: 8706J RHR 32D
- Configuration: Rim exit device
- Door Width: 24" to 32" (E Rail, no cutting required for 32")
- Door Thickness: 1 3/4" (44mm)
- Minimum Stile Width: 4 1/2" (114mm) with trim; 3 1/2" (44mm) without trim
- Standards: Exceeds ANSI/BHMA Grade 1
- Features: Modular construction, few moving parts, maintenance-free
- Options: Delayed egress, alarmed exit, electric latch retraction
