Description
The Yale 8834FL 626 is a commercial-grade mortise lock built for high-security applications in offices, hospitals, schools and other institutional settings. Its reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim and ANSI/BHMA Grade 1 certification deliver uncompromising strength and durability where security matters most.
This lock fits standard 1-3/4 inch doors and features a field-reversible latchbolt, quick lever handing and non-handed strike for easy installation. As an authorized Yale dealer, E.D. Locks offers expert product guidance and compatibility support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 with questions about keying options, finishes or special requirements.
Specifications
- ANSI/BHMA Certified A156.13, Series 1000, Grade 1
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Mechanism: Stainless steel
- Backset: 2-3/4 inch
- Latchbolt: 3/4 inch stainless steel throw
- Door thickness: 1-3/4 inch standard, to 3-1/4 inch available
- Front: Bevel front, free-floating 1/8 inch adjustment
- Cylinders: Brass, 6-pin keyed-random with two keys, 7-pin available
- Field reversible handing
- Strike: 1-1/4 inch curved lip for 1-3/4 inch door, reversible
- Available in 17 finishes
- Warranty: 10 years mechanical
