Description
The BEST 9K is a Grade 1 cylindrical lock engineered for high-security, low-maintenance performance across commercial and institutional applications. Built to withstand over 4 million cycles and designed with protected lever return springs, this lock reduces maintenance needs and extends service life compared to standard alternatives, lowering total cost of ownership.
Compatible with 1 3/4" and 2 1/4" doors, the 9K features quick-change interchangeable core keying (6-pin or 7-pin SFIC options), multiple keyway choices, and pre-assembled hub design for simple installation. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert keying guidance and authorized dealer support.
Specifications
- Grade: Grade 1 cylindrical lock
- Latch: solid stainless steel, 9/16" throw; front 2 1/4" and 1 1/8" beveled
- Lever handles: plated zinc alloy
- Trim: brass or bronze
- Strike: ANSI 2 3/4" standard; ANSI S3 4 7/8", ANSI S3 7/8" flat, and 7/8" flat strike (STK) available
- Chassis: zinc alloy and corrosion-treated steel; 2 1/16" diameter
- Door thickness: 1 3/4" or 2 1/4"; spacers available for 1 3/8" door
- Door prep: 2 1/8" diameter cross bore
- Backset: 2 3/4" standard; 3 2/4" and 5" available
- Keying: 6-pin non-IC brass cylinder; 6-pin or 7-pin SFIC option available
- Keyway options: LFIC (SCHRC-Schlage), Non-IC (COR-Corbin-Russwin, MED-Medeco, SAR-Sargent, SCH-Schlage, YAL-Yale)
- Cycle rating: over 4 million cycles (exceeds ANSI Grade 1 standard)
