Description
The Yale 8800 Series Mortise Lock is a heavy-duty commercial lock engineered for maximum security and durability in demanding environments. Featuring a reinforced stainless steel deadbolt, vandal-resistant trim, and ANSI/BHMA Grade 1 certification, this lock solves the need for reliable access control in high-traffic commercial doors.
Field-reversible handing and quick lever installation make setup straightforward on standard 1-3/4" doors. This 626 trim pack comes keyed-random with two keys included. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying options, and compatibility. Contact us at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- ANSI/BHMA A156.13 Series 1000, Operational Grade 1 certified
- UL/cUL fire rated up to 3 hours
- Backset: 2-3/4 inches
- Latchbolt: 3/4 inch stainless steel throw
- Door thickness: 1-3/4 inch standard (up to 3-1/4 inch available)
- Mechanism: Stainless steel
- Cylinders: Brass, 6-pin keyed-random with two keys standard
- Strikes: 1-1/4 inch curved lip for 1-3/4 inch doors, reversible
- Field reversible handing
- Available in 17 finishes
- 10-year mechanical warranty
