Description
The Yale 8800 Series mortise lock delivers commercial-grade security with ANSI/BHMA Grade 1 certification and reinforced stainless steel deadbolt. Designed for high-traffic doors in offices, retail, and institutional settings, this lock provides uncompromising strength and vandal resistance with field-reversible handing for flexible installation.
The AUR838BFL fits standard 1-3/4" doors and accommodates thicker doors to 3-1/4" by special order. UL/cUL fire-rated up to 3 hours and windstorm-certified. For keying options, compatibility verification, or finish selection from 17 available colors, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- ANSI/BHMA: Certified A156.13, Series 1000, Operational Grade 1
- UL-cUL: Fire rated up to 3 hours
- Windstorm: Certified (refer to local codes)
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard, to 3-1/4" thick doors to order
- Fronts: Bevel front, free-floating to adjust from flat to standard bevel of 1/8" in 2"
- Cylinders: Brass, 6-pin, keyed-random with two keys standard; 7-pin available to order
- Reversibility: Field reversible handing
- Strikes: 1-1/4" curved lip for 1-3/4" door standard; other lip lengths to special order; all reversible
- Finishes: Available in 17 finishes
- Warranty: 10 year mechanical
