Description
The Yale 8800 Series MOR8864FL mortise lock delivers ANSI/BHMA Grade 1 security for commercial doors. Built with a reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim, this lock handles high-traffic applications demanding uncompromising strength and durability. Field-reversible latchbolt and quick lever handing simplify installation.
Compatible with 1-3/4" standard doors (up to 3-1/4" available to order). Includes a 6-pin keyed-random cylinder with two keys; 7-pin upgrade available. As an authorized Yale dealer, E.D. Locks offers expert product selection and support. Contact our team at sales@edlocks.com or 1-877-207-6067 for keying options, finish details, or custom configurations.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4 inches
- Latchbolt: 3/4 inch stainless steel throw
- Door Thickness: 1-3/4 inch standard (up to 3-1/4 inch to order)
- Front: Bevel front, free-floating (flat to 1/8 inch standard bevel)
- Cylinder: 6-pin brass, keyed-random with two keys (7-pin available)
- Strike: 1-1/4 inch curved lip for 1-3/4 inch door (other sizes available)
- Reversible: Field reversible handing and strike
- Finishes: 17 available options
- Warranty: 10 years mechanical
