Description
The Yale 8800 Series mortise lock delivers ANSI/BHMA Grade 1 commercial-grade security for office buildings, hotels, and institutional facilities. This reinforced stainless steel deadbolt resists vandalism and provides uncompromising strength in high-traffic applications. Field-reversible handing and quick lever installation simplify deployment across multiple door types.
Compatible with standard 1 3/4" doors and adjustable to 3 1/4" thickness. The lock features a 6-pin keyed-random cylinder with two keys included; 7-pin cylinders available on request. As an authorized Yale dealer, E.D. Locks provides expert guidance on keying, finishes, and compatibility. Contact sales@edlocks.com or call 1-877-207-6067 for personalized assistance.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Windstorm Certified: Yes (refer to local codes)
- Mechanism: Stainless steel
- Backset: 2 3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1 3/4" standard, to 3 1/4" on order
- Front: Bevel front, adjustable flat to 1/8" standard bevel
- Cylinder: Brass, 6-pin keyed-random, two keys included, 7-pin available
- Handing: Field reversible
- Strike: 1 1/4" curved lip for 1 3/4" doors, reversible
- Finishes: 17 available
- Warranty: 10 years mechanical
