Description
The Yale 8800 Series mortise lock trim pack delivers Grade 1 security for commercial doors requiring uncompromising strength and durability. Featuring a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and field-reversible handing, this lock solves security and installation challenges for property managers, contractors, and facility directors.
Compatible with standard 1-3/4" doors and available for thicker doors to 3-1/4" by special order, the AUR8818-2FL includes a curved lip strike, 6-pin keyed-random cylinder with two keys, and adjustable bevel front. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying options, and compatibility. Contact sales@edlocks.com or 1-877-207-6067 for personalized assistance.
Specifications
- ANSI/BHMA A156.13 Certified, Grade 1
- UL/cUL Fire Rated: Up to 3 hours
- Windstorm Certified
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (to 3-1/4" by special order)
- Bevel Front: Free-floating, 1/8" to standard bevel adjustment
- Cylinder: Brass, 6-pin keyed-random (7-pin available)
- Includes: Two keys
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths available)
- Reversibility: Field reversible handing
- Mechanism: Stainless steel
- Available Finishes: 17 options
- Warranty: 10-year mechanical
