Description
The Yale 8835 FL mortise lock is a Grade 1 commercial-duty lock built for uncompromising strength in retail, office, and institutional applications. It features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and ANSI/BHMA A156.13 certification for long-term reliability and security compliance.
This lock suits standard 1-3/4" doors and accommodates thicker doors up to 3-1/4" on special order. Field-reversible handing, quick lever installation, and a nonhanded strike simplify job setup. Contact our team at sales@edlocks.com or 1-877-207-6067 for finish selection guidance, keying options, or technical questions. As an authorized Yale dealer, we provide expert support and fast shipping.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Standard Door Thickness: 1-3/4" (up to 3-1/4" available)
- Front: Bevel front, free-floating (flat to 1/8" standard bevel)
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available)
- Field Reversible: Yes
- Strike: 1-1/4" curved lip for 1-3/4" doors (reversible)
- Finishes: 17 available
- Warranty: 10 years mechanical
