Description
The Yale AUR8865FL 626 is a heavy-duty mortise lock trim pack engineered for commercial doors requiring ANSI/BHMA Grade 1 security. Designed for uncompromising strength, it features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing. Ideal for high-traffic commercial buildings, educational facilities, and institutional applications where durability and reliable access control matter.
This trim pack fits standard 1-3/4" doors and includes a 6-pin brass cylinder with two keys. The latchbolt and strike are fully reversible, simplifying installation on either hand. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, keying options, and compatibility. Contact our sales team at 1-877-207-6067 or sales@edlocks.com for technical support or custom configurations.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available to order)
- Cylinder: Brass, 6-pin, keyed-random with two keys (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths to special order)
- Finishes: 17 finishes available
- Warranty: 10 year mechanical
- Reversibility: Field reversible handing
