Description
The Falcon B511LD Q 605 is a Grade 2 cylindrical lockset built for government, military, retail, industrial and multi-family applications. It combines durability with quick re-keying capability through its interchangeable SFIC core, making it an ideal replacement for existing locks or new construction projects requiring reliable security and style.
This lock fits standard doors 1 3/8" to 2" thick with 2 3/4" or 2 3/8" backset options. Non-handed design simplifies installation on any door orientation. Components are brass or cold-formed steel with zinc plating and dichromate finish for rust resistance; springs are stainless steel. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying, compatibility, and authorized dealer support.
Specifications
- Grade: 2
- Door Thickness: 1 3/8" to 2" standard
- Backset: 2 3/4" standard, 2 3/8" also available
- Mechanism: Brass or cold-formed steel parts, zinc plated and dichromated, stainless steel springs
- Cylinders: 6-pin chambers, pinned in 5 (6-pin pinning available at no cost)
- Cylinder Type: Removable SFIC, compatible with other manufacturers' SFIC products; 6 or 7-pin interchangeable core also available
- Cylinder Material: Solid brass housings and plugs, phosphor bronze springs
- Keys: Two nickel silver keys furnished standard
- Handing: Non-handed
- Finish: Satin Brass (605)
