Description
The DormaKaba B76-N1EN10-626 is a heavy-duty Grade 1 commercial inside housing for E203X exit devices. Built with solid cast construction and cylindrical drive technology, it solves security and durability needs for indoor and outdoor applications requiring reliable access control on non-handed doors.
This housing fits 2¾" and 2⅜" cylindrical backsets, plus 2¾" mortise backset, and ships with both ANSI strike options. Pre-assembled for left-hand installation with field-adjustable handing. For compatibility verification, keying setup, or technical questions, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- Brand: DormaKaba
- Model: B76-N1EN10-626
- Grade: 1 (ANSI/BHMA)
- Finish: Satin Chrome
- Handing: Non-handed (field adjustable for left-hand)
- Cylindrical Backset: 2¾" (70 mm) and 2⅜" (60 mm)
- Mortise Backset: 2¾" (70 mm)
- Latch Throw: ½" (13 mm) or ¾" (19 mm) cylindrical; ¾" (19 mm) or 1" (25 mm) mortise deadbolt optional
- Strikes Included: ANSI A115.3 "T" Strike and A115.2 ASA Strike
- Minimum Stile Required: 5" (127 mm)
- Cylinder: Kaba 1539 6-pin, Schlage "C" Keyway
- Interchangeable Core: Small format (6 or 7-pin, cylinder not included)
- Construction: Solid cast exterior housing and levers
