Description
The Von Duprin CD35AEO 3 is a UL-listed rim exit device engineered for single and double doors with mullions. Grade 1 ANSI A156.3-2014 certified, it delivers reliable panic hardware performance for commercial facilities, schools, hospitals, and high-traffic venues requiring code-compliant emergency egress solutions.
Compatible with doors 28 inches to 48 inches wide, the CD35AEO 3 mounts on the interior and features a deadlocking latch bolt with 3/4-inch throw. Installation requires standard wood or metal door fasteners (SNB included). For proper sizing, compatibility verification, and keying options, contact our authorized dealer specialists at sales@edlocks.com or call 1-877-207-6067 for expert guidance.
Specifications
- Brand: Von Duprin
- Model: CD35AEO 3
- Finish: US28 Satin Aluminum
- Device Length: 2 feet 4 inches to 3 feet (711 mm to 914 mm)
- Door Size: 2 feet 10 inches to 4 feet (864 mm to 1219 mm)
- Center Case Dimensions: 8 3/16 inches x 1 9/16 inches x 2 13/32 inches
- Mechanism Case Dimensions: 2 1/4 inches x 2 1/4 inches
- Pushbar Projection (Neutral): 3 13/16 inches
- Pushbar Projection (Depressed): 3 1/16 inches
- Latch Bolt Throw: 3/4 inch, Deadlocking
- Device Centerline from Floor: 39 13/16 inches (standard), 39 11/16 inches (with mullion)
- Certification: UL Listed, ANSI A156.3-2014 Grade 1
- Application: Single and Double Doors with Mullion
- Handed: Non-handed (except with signal switch option)
