Description
The Von Duprin RXEL35AEO is a UL-listed rim exit device designed for single and double doors with mullions. ANSI A156.3-2014 Grade 1 certified, this panic hardware features a smooth mechanism case and deadlocking latch bolt, solving emergency egress requirements for commercial buildings, hospitals, schools, and high-traffic facilities.
Compatible with door widths from 2'10" to 4' and device lengths from 2'4" to 3', the RXEL35AEO installs on either side of the door (non-handed except with signal switch option). As an authorized Von Duprin dealer, E.D. Locks provides expert sizing assistance and free shipping on orders over $450. Contact our team at sales@edlocks.com or 1-877-207-6067 for compatibility verification and installation support.
Specifications
- Brand: Von Duprin
- Model: RXEL35AEO
- Finish: US28 Satin Aluminum
- Device Centerline: 39 13/16" from finished floor (39 11/16" with mullion)
- Center Case Dimensions: 8 3/16" x 1 9/16" x 2 13/32"
- Mechanism Case Dimensions: 2 1/4" x 2 1/4"
- Pushbar Projection (Neutral): 3 13/16"
- Pushbar Projection (Depressed): 3 1/16"
- Latch Bolt: Deadlocking, 3/4" throw
- Door Width Range: 2'10" to 4'
- Device Length Range: 2'4" to 3'
- Certification: UL Listed, ANSI A156.3-2014 Grade 1
- Application: Single and double doors with mullion
