Description
The Yale 8800 Series mortise lock trim pack is engineered for commercial doors demanding uncompromising strength and durability. This ANSI/BHMA Grade 1 certified lock features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and field-reversible handing, making it ideal for high-traffic office buildings, healthcare facilities, and institutional applications where security and longevity matter.
The trim pack fits standard 1-3/4" doors and includes a 3/4" stainless steel latchbolt, 6-pin keyed-random cylinder with two keys, and a curved lip strike. All components are field-reversible for flexible installation. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying options, and installation support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for specifications and custom requirements.
Specifications
- Brand: Yale/Accentra
- Series: 8800
- Certification: ANSI/BHMA A156.13, Series 1000, Grade 1; UL/cUL fire rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (to 3-1/4" available to order)
- Cylinders: Brass, 6-pin keyed-random (7-pin available to order)
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths to special order)
- Finishes: Available in 17 finishes
- Warranty: 10 year mechanical
