Description
The Yale 8800 Series mortise lock trim pack delivers ANSI/BHMA Grade 1 commercial-grade security for interior and exterior doors. Built for high-traffic commercial applications, this reinforced stainless steel deadbolt resists vandalism and meets fire-rated performance up to 3 hours. Field-reversible handing and quick lever installation make setup fast and flexible.
Compatible with standard 1-3/4" door thickness (custom depths available). The 6-pin keyed-random cylinder includes two keys; 7-pin upgrades are available. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, handing, and keying options. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for personalized support and quotes on bulk orders.
Specifications
- Certification: ANSI/BHMA A156.13 Series 1000, Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available)
- Cylinder: Brass, 6-pin keyed-random with 2 keys
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip (reversible, other lengths available)
- Finishes: 17 standard options
- Warranty: 10-year mechanical
