Description
The Yale 8800 Series mortise lock is a commercial-grade deadbolt designed for interior and exterior doors in offices, hotels, and institutional buildings. It delivers ANSI/BHMA Grade 1 security with a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and field-reversible installation. This lock solves the need for reliable, durable access control in high-traffic commercial environments.
This mortise lock fits standard 1-3/4" doors and accommodates doors up to 3-1/4" thick by special order. It comes keyed-random with two keys and includes a standard curved-lip strike. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, keying options, and custom configurations. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for assistance.
Specifications
- Brand: Yale/Accentra
- Series: 8800
- Certification: ANSI/BHMA A156.13 Grade 1, UL/cUL fire-rated to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" by order)
- Front: Bevel front, free-floating 1/8" adjustment
- Cylinder: Brass, 6-pin keyed-random with 2 keys (7-pin available)
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip, reversible (other lengths by order)
- Finishes: 17 finishes available
- Warranty: 10 years mechanical
