Description
The Corbin Russwin DL3012 is a non-handed deadlock designed for standard 1-3/4" and 2-1/4" doors. Built for commercial and institutional applications, this deadlock delivers a hardened steel 1" throw bolt with secure cylinder locking, ideal for facilities requiring reliable perimeter security without complex installation.
The DL3012 features a brass 6-pin cylinder with L4 keyway, wrought brass or bronze front, and standard 2-3/4" backset. Master keying, interchangeable core, and security cylinder options are available to match your access control needs. As an authorized Corbin Russwin dealer, E.D. Locks provides expert configuration guidance and fast shipping. Contact sales@edlocks.com or call 1-877-207-6067 for keying assistance.
Specifications
- Brand: Corbin Russwin
- Model: DL3012 612 LC
- Handing: Non-handed
- Door Thickness: 1-3/4" (44mm) and 2-1/4" (57mm)
- Standard Backset: 2-3/4" (70mm); Optional: 2-3/8" (60mm)
- Front: Wrought brass or bronze, 2-1/4" x 1-1/8"
- Deadbolt: Zinc diecast hardened steel, 1" throw, 5/8" wide x 3/4" high
- Cylinder: Brass, 6-pin, L4 keyway
- Strike: 2-3/4" x 1-1/8"
- Keys: Two nickel silver (standard)
- Keying Options: Master keying, construction master keying, interchangeable core (IC), security, pyramid
- Warranty: One-year limited
