Description
The Corbin Russwin DL3013 is a non-handed deadlock designed for standard 1-3/4" to 2-1/4" doors. Built with a hardened steel insert and 1" throw bolt, it delivers reliable security for commercial and institutional applications. Ideal for facilities needing durable, field-reversible locking hardware.
This lock features a brass 6-pin cylinder with L4 keyway and comes with two nickel silver keys. Master keying, interchangeable core, and security cylinder options are available to match your access control needs. As an authorized Corbin Russwin dealer, E.D. Locks provides expert guidance on configuration and installation. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for keying assistance and fast shipping on orders over $450.
Specifications
- Brand: Corbin Russwin
- Model: DL3013 626 CL6
- Handing: Non-handed
- Door Thickness: 1-3/4" to 2-1/4" (standard)
- Backset: 2-3/4" (standard); 2-3/8" (optional)
- Front: Wrought brass or bronze, 2-1/4" x 1-1/8"
- Deadbolt: Zinc diecast hardened steel, 1" throw, 5/8" wide x 3/4" high
- Strike: 2-3/4" x 1-1/8"
- Cylinder: Brass, 6-pin, L4 keyway
- Keys: Two nickel silver
- Keying Options: Master keying, construction master keying, interchangeable core (IC), security, pyramid
- Warranty: One-year limited
